Electrical data

Nominal input voltage 220…240 V
Mains frequency 50/60 Hz
Input voltage AC 198…264 V
Nominal input current at 230 V 0.16 A
Total harmonic distortion < 15 %
Power factor λ 0.88C...0.95
Efficiency in full-load 92 %
Device power loss 2.3 W
Inrush current 16.4 A
Max. ECG no. on circuit breaker 10 A (B) 21
Max. ECG no. on circuit breaker 16 A (B) 34
Surge capability (L-N) 1 kV
Surge capability (L/N-Ground) 2 kV
Protective conductor current not relevant
Nominal output voltage 30…40 V
U-OUT (working voltage) 60 V
Nominal output current 600/700 mA
Default output current 700 mA
Output current tolerance ±5 %
Output ripple current (100 Hz) ≤ 3 %
Output PSTLM ≤1
Output SVM ≤0.4
Nominal output power 18…28 W
Maximum output power 28 W
Galvanic isolation primary/secondary SELV
